Getting started with OptiView Ads on iOS

This guide will get you started to integrate OptiView Ads in your OptiView Player iOS SDK: configure the license, update dependencies and set the source description.

Prerequisites​

  1. You need to have an OptiView Player license which is compatible with OptiView Ads. This can be done through the player portal.

  2. You need a correctly deployed OptiView Ads signaling service.

  3. Add the OptiView Player iOS SDK to your project by following our Getting started guide. Make sure to set up an OptiView Ads-compatible license in your app.

  4. Add the OptiView Ads integration as a dependency to your project:

    1. Add the THEOplayer-Integration-THEOads pod to your Podfile:
    pod 'THEOplayer-Integration-THEOads', '~> <YOUR_INTEGRATION_VERSION>'
    1. Install the new pod:
    pod install

  5. Add Google IMA SDK as a dependency to your project:

    1. The THEOplayer-Integration-THEOads pod has a dependency on GoogleAds-IMA-iOS-SDK which should be installed automatically.

Integration​

To make use of the OptiView Ads integration, create and add the THEOadsIntegration to your THEOplayer instance:

import UIKit
import THEOplayerSDK
import THEOplayerTHEOadsIntegration

class ViewController: UIViewController {
    var theoplayer: THEOplayer!
    var theoads: THEOadsIntegration!

    override func viewDidLoad() {
        super.viewDidLoad()
        self.theoplayer = THEOplayer(configuration: THEOplayerConfigurationBuilder().build())
        self.theoplayer.frame = view.bounds
        self.theoplayer.addAsSubview(of: view)
        self.theoads = THEOadsIntegrationFactory.createIntegration(on: self.theoplayer)
        self.theoplayer.addIntegration(self.theoads)
    }

}

Then, configure a source containing a THEOAdDescription:

import UIKit
import THEOplayerSDK
import THEOplayerTHEOadsIntegration

class ViewController: UIViewController {
    var theoplayer: THEOplayer!
    var theoads: THEOadsIntegration!

    override func viewDidLoad() {
        super.viewDidLoad()
        self.theoplayer = THEOplayer(configuration: THEOplayerConfigurationBuilder().build())
        self.theoplayer.frame = view.bounds
        self.theoplayer.addAsSubview(of: view)
        self.theoads = THEOadsIntegrationFactory.createIntegration(on: self.theoplayer)
        self.theoplayer.addIntegration(self.theoads)

        let source = "PATH-TO-SIGNALING-SERVER/hls/MANIFEST-URI"
        let typedSource = TypedSource(
            src: source,
            type: "application/x-mpegurl",
            hlsDateRange: true
        )
        let theoad = THEOAdDescription(
            networkCode: "NETWORK-CODE",
            customAssetKey: "CUSTOM-ASSET-KEY"
        )
        let sourceDescription = SourceDescription(source: typedSource, ads: [theoad])
        self.theoplayer.source = sourceDescription
        self.theoplayer.play()
    }

}
  • Notice that the src is different as usual. For OptiView Ads, a signaling server needs to be set up which acts as a proxy to parse the given manifest and insert the ad interstitials. More information can be found here.
  • The hlsDateRange flag needs to be set to true as the ad markers are done using EXT-X-DATERANGE tags.
  • The ads array needs to contain a THEOAdDescription. Furthermore, the networkCode and customAssetKey needs to be set according to your configured Google account.
